Core filter
GV-CB3 Video
Capture Box
Core filter
To JLIP
connector
To S-Video input
connector
To video input
connector
Rear-panel connectors
To video output
connector
Front-panel
connectors
JLIP
To digital
connector
(8-pin)
Core filter
PC connection
cable (provided)
To COM port
(RS-232C)
Personal computer
* Connect this if you are not using batteries in
the Video Capture Box.
JLIP
Core filter
* AC adapter
(AA-V701EG/EK)
(optional)
9
EN
To AC
outlet
