1.) Den Kaltgerätestecker (1) in die Buchse (2)
unten am Filterkasten stecken. Stellen Sie
sicher, dass der Sicherungsring des Steckers
unter der Kante (3) einrastet.
2.) Dann das Kabel von unten nach oben in die
Führung (4) in der Halterung des Teleskoprohres
einlegen und hinter die Haltenasen (5) drücken.
3.) Auf der Geräteoberseite an der Führungsleiste
(6) anlegen und von hinten durch die Halteöse
(7) führen.
4.) Am Stiel entlang zur zweiten Halteöse (8) am
Griff führen und dort einlegen.
5.) Eine Schlaufe bilden, diese in die Zugentlastung
(9) neben der Taste „PUSH" (10) einschieben
und vorsichtig straffen.
6.) Schließlich das restliche Kabel über die Auflage
am Griff (11) und den drehbaren Kabelhaken
(12) aufwickeln.
Um das Kabel aus der Zugentlastung zu lösen,
die Taste „PUSH" (10) betätigen und die Schlaufe
herausziehen.
