Nivel System N24x Bedienungsanleitung Seite 5

Calibration: Remove the eyepiece cover. Gently turn the calibration screw to crosshair set the
calculated earlier value on a staff in example 1,484m. Replace the eyepiece cover.
General notes
The following suggestions will help in the long comfortable work of level:
1. After finishing the measurements, clean the level before
putting it in box.
2. For cleaning lens use soft brush or special cloths. Never touch the lens by fingers
3. If the instrument was damaged or it doesn't work properly it should be fixed by authorized
service.
4. The level should be kept in clean, dry and breezy place.
5. While transporting the level you should avoid impacts and vibrations.
GENERAL NOTES
The following suggestions will help in the long comfortable work of level:
1. After finishing the measurements, clean the level before putting it in box.
2. For cleaning lens use soft brush or special cloths. Never touch the lens by fingers
3. If the instrument was damaged or it doesn't work properly it should be fixed by authorized
service.
4. The level should be kept in clean, dry and breezy place.
5. While transporting the level you should avoid impacts and vibrations
SPECYFICATION
Telescope
Length
Magnification
Diameter
Resolving power
Field of view
Minimum focus
Standard deviation for 1km of double run levelling
Accuracy
Automatic compensator
Type
Horizontal circle
Graduation
Pozostałe informacje
Water resistance
Operating temperature range
Size
Weight
Producer:
TPI Sp. z o. o., 598 Wał Miedzeszyński, 03-994 Warsaw, Poland,
VAT: PL5270205140
+48 22 632 91 40, info@nivelsystem.com
Country of production: China
N24x
215 mm
24x
42 mm
3,5"
1°20'
0,3m
erect
2,0mm
magnetic
1gon / 1°
IPX6
-20°C do +50°C
130 x 215 x 140mm
1,75kg
5
N32x
32x
1,5mm
