INSTRUCTION MANUAL I ENGLISH
OPERATION
- Screw the Muted+ RTA onto a mod.
- Rotate the tank counterclockwise while pulling it upwards
to detach it from the base.
- Prepare a coil (pass the wire under the coil aid;
we recommend a 2.5 mm inner diameter) and place the coil aid on the deck.
Insert the wire ends into the designated slots and tighten the post screws.
Remove excess wire to avoid contact with other components.
✓
- The pre-installed 0.6 mm side airflow pins can be swapped when the tank is
removed. The 0.8 mm bottom airflow screw can be changed by replacing the
510 positive pin.
18
English
✗
Vaping
1
(Liquid control open)
Tank removal
2
Filling and transport
(Liquid control closed)
When reattaching the tank, ensure
that the logos on the tank
align with the bayonet locks on
the deck.
English
19
