GRE RAPID Einbau- Und Betriebsanleitung Seite 23

Tropical Red
Paradise
Red
Abril
Pale violet
Eleven
Red
- Refresh button
In pools with more than one lamp, this button is used to synchronise them.
If one of the lamps fails to respond to the COLOR/SEQUENCE commands, press the REFRESH button on the lamp and the
last command will be sent so that it synchronises with the others.
- Selecting the speed of sequences
The -/+ buttons enable you to select one of the eight sequences, ordered from the slowest to the fastest speed.
- Switching spotlights off
The spotlights are turned off by pressing the ON/OFF button. The status (colour/sequence) of the lamps is stored in the
memory for the next time the system is switched on.
- Switching the remote control off
The remote control automatically switches off in less than 60 seconds.
The LED display lights on the remote control only light up for a few seconds.
3.2 Control motion mode (see page 23)
When the control motion mode is switched on, the colours and sequences can be changed.
Changing the colour (Fig. A)
- Hold the remote control firmly without touching any of the buttons.
- Flick your wrist downwards.
- The change in colour will be displayed on the Central Display.
Changing the sequence (Fig. B)
- Hold the remote control firmly without touching any of the buttons.
- Flick you wrist form side to side.
- The change in sequence will be displayed on the Central Display.
4. CONTROL MOTION MAINTENANCE:
If the Central Display lights up in red without switching off, this means the batteries are low. The battery case is on the back
of the Control Motion unit; replace the old batteries with two new AAA 1.5 V ones.
5. WIRING:
Diagram of the wiring (see page 23)
In order to wire the system properly, a lamp, transformer and the Control Motion unit will be needed.
The transformer should be connected to a 230 V~ac power supply and the lamp (12 V~ac) to the auxiliary winding.
It must be sized to supply the corresponding VA to each LED lamp that is wired (see table on the back cover). For example, if
you wish to control two 37VA PAR56 1.11 lamps they must be wired in parallel to the transformer to at least 74VA.
Alternatively, the system can be controlled using a simple NC push button, in which case there will be 14 function modes:
seven set colours and seven different colour sequences. Each time the push button is pressed, the colour or sequence will
change. By pressing for several seconds, the light becomes white.
6. TROUBLESHOOTING:
Problems
The lamp or spotlight is not working
The lamp projects a different colour
to that shown on the Control Motion
Central Display
Two lamps project different colours
Using the control motion mode, the
lamp or spotlight does not work
Control Motion is not responding
Pink Blue Pink
Orange Green Cyan
Magenta Cyan Yellow
Green Blue Yellow
The lamp or spotlight does not have a
power supply
The lamp/s or spotlight/s do not
receive information
The Control Motion batteries are low
Blue Pink
White Yellow Cyan Magenta
Cyan Magenta Pale Sky-blue
violet
Usual causes
3
Orange Pink Esmerald White
green
Solutions
Connect the lamp or spotlight
to the power supply through a
12 V~ac safety transformer.
1. Get close to the lamp or
spotlight before sending a
command
2. Do not cover the antenna
with your hand
3. Press the REFRESH button
Change the batteries
