Bitmap Table „Extended"
3.1.8
Additional functions, such as Alarm functions are listed in Bitmap table .
Tabelle 8
Bitmap table for extended Functions
Bit No. Name
0
1
2
3
4
5-31
Table „Operating States"
3.1.9
Tabelle 9
Table „Operating states"
Value
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
28
S O N D E R D O K U M E N T A T I O N
8030789/AE00/V1-0/2014-05
Alarm purge air
Alarm optic housing temperature
Alarm lamp current
Alarm lamp integration
Alarm pressure (pressure < 800 hPa or pressure > 1300 hPa)
Reserved
Operating state
not defined
Initialisation
Measuring
Maintenance
RCycle
Check cycle
ZeroAdjust
Alignment
Boxmeasuring
Restart
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
Reserved
GM32
Comment
Bit=1: active
Bit=1: active;
Bit=1: active;
Bit=1: active;
Bit=1: active
