Anhang
Mapping der Modbus Eingabewerte
3.1.3
● Modbus Register für Eingabewerte, gültig für alle gemessenen Komponenten
Tabelle 3 Modbus Eingabe Register
Item
Pressure
Temperature
Humidity
Password
Pressure valid flag
Temperature valid flag
Humidity valid flag
Maintenance switch
Trigger control cycle
Supress control cycle
0) Bit field, please see table "Status" for details. → S. 26, Tabelle 4
1) Current date and time of the device in ISO8601 format
2)
Bit field, please see table "Failure" for details, → S. 27, Tabelle 5
3) Bit field, please see table "Maintenance request" for details, → S. 27, Tabelle 6
4) Bit field, please see table "Function check" for details, → S. 27, Tabelle 7.
5) Bit field, please see table "Out of Spec" for details.→ S. 27, Tabelle 7
6) Bit field, please see table "Extended" for details, → S. 28, Tabelle 8
8)
For table of operating states please see table "Operating states" for details, → S. 28,
Tabelle 9
9) Date and time of last Controll check cycle for all components of the GM32
10)
Sticky: functions like a switch
11) Momentary: functions like a push button
Table Bitmap „Status"
3.1.4
Tabelle 4 Bitmap „Status"
Bit No. Name
0
1
2
3
4
5
6
7
26
S O N D E R D O K U M E N T A T I O N
8030789/AE00/V1-0/2014-05
Address
Start Width
6000 2
6002 2
6006 2
6900 3
6000 1
6001 1
6002 1
6003 1
6004 1
6005 1
Comment
Failure Bit=1: active
Maintenance request Bit=1: active
Function Check Bit=1: active
Out of Spec Bit=1: active
Extended Bit=1: active
Under range Bit=1: active
Over range Bit=1: active
Maintenance Bit=1: active
Data type Register type
32 Bit float Holding register
32 Bit float Holding register
32 Bit float Holding register
string Holding register
1 Bit Coil
1 Bit Coil
1 Bit Coil
1 Bit Coil
1 Bit Coil
1 Bit Coil
Bit No. Name
8 Check cycle
9 Reserved
10 Reserved
11 Reserved
12 Reserved
13 Reserved
14 Reserved
15 Reserved
Comment
sticky 10)
sticky 10)
sticky 10)
sticky 10)
momentary 11)
sticky 10)
Comment
Bit=1: active
Bit=1: active
Bit=1: active
Bit=1: active
Bit=1: active
Bit=1: active
Bit=1: active
Bit=1: active
