Austroflamm WiRCU-BOX Benutzerhandbuch Seite 26

1 | Mounting the WiRCU-BOX
1 Mounting the WiRCU-BOX
1.1 Included in the OPTIONAL WiRCU-Box
WiRCU-Box
WARNING
The WiRCU-Box must not come into contact with water, cleaning agents, solvents or other liquids.
These will damage the box's electronics and cause malfunctions.
Technical characteristics:
• Temperature range for storage and operation: -20°C to +60°C
• Permissible air humidity for storage and operation: max. 95 %, non-condensing
• Wireless type: 802.11 b/g/n 2.4 GHz
• Host controller link: proprietary protocol
• Dimensions: 76 x 51 x 23 mm
• Mounting on stove: 2 screws (hexagon socket M4x8)
• Connections: Micro USB connection for firmware update, RJ11 connection for communication and
power supply
• Protection class: IP20 - when mounted in recommended position
Technical requirements for the WLAN network:
• Wireless type: 802.11 b/g/n 2.4 GHz
• Security encryption: WPA2 or clear/unencrypted
• No MAC address filtering
• TCP ports 5001 & 5101 must be activated
For the correct configuration of your WLAN router please contact your IT administrator or IT specialist.
26
EN
1.5 m data cable Information card with MAC
address and PIN number
WiRCU-BOX
