Digital thermo-hygrometer
Caution!
Risk of injury:
• Keep this device and the battery out of reach of children.
• Small parts can be swallowed by children (under three years old).
• Batteries contain harmful acids and may be hazardous if swallowed. If a battery is swallowed, this can
lead to serious internal burns and death within two hours. If you suspect a battery could have been
swallowed or otherwise caught in the body, seek medical help immediately.
• Batteries must not be thrown into a fire, short-circuited, taken apart or recharged. Risk of explosion!
• Low batteries should be changed as soon as possible to prevent damage caused by leaking.
• Avoid contact with skin, eyes and mucosa when handling leaking batteries. In case of contact, immedi-
ately rinse the affected areas with water and consult a doctor.
Important information on product safety!
• Do not expose the device to extreme temperatures, vibrations or shocks.
• Protect it from moisture.
5. Elements
Buttons
A: SET button
B: SWITCH button
C: MAX/MIN button
Housing
D: Wall mounting hole
E: Stand (removable)
F: Battery compartment
6. Getting started
• Remove the stand by carefully pulling it downwards.
12
15.04.2025 10:17 Uhr Seite 7
Digital thermo-hygrometer
• Open the battery compartment by turning the lid with a coin counterclockwise. Remove the insulation
strip.
• Close the battery compartment again.
• All LCD segments will light up for about a few seconds.
• The unit is now ready to use.
• The upper display shows the time and the comfort level, the middle display shows the current tempera-
ture and the lower display the relative humidity.
7. Setting of clock
• After battery was activated or press and hold SET button for 3 seconds, you will enter the time setting
mode.
• The hour digit is flashing.
• Press SWITCH button to adjust the hours.
• Press SET button again and set minutes in the same way.
• Hold and press the button for a fast count.
• Press SET button to confirm it.
8. Temperature display
• Press SET button to change between °C (Celsius) or °F (Fahrenheit) as temperature unit in normal
mode.
• With Fahrenheit as temperature unit, the clock automatically switches to the 12 HR system (PM
appears on the display after noon).
9. MAX/MIN values
• Press MAX/MIN button.
• MAX appears on the display. The maximum temperature and humidity are displayed.
• Press the button again.
• MIN appears on the display. The minimum temperature and humidity are displayed.
• Press MAX/MIN button again to return to normal mode.
• Press SET button in the respective mode to clear the recorded MAX/MIN reading.
• --.- °C and --.- % appear on the display.
