Solar panels in both series and parallel

d
Solar
panel 1
100W 100W
100W 100W
Solar
panel 3
d
Solar
panel 5
100W 100W
100W 100W
Solar
panel 7
15
BKW-Solar
cable
a
X1
Solar
panel 2
100W 100W
100W 100W
Solar
panel 4
Solar
panel 6
100W 100W
100W 100W
Solar
panel 8
Vm (solar panel 1) + Vm (solar panel 2) < 55V
Im (solar panel 1) + Im (solar panel 2) < 13A
Extension cable
b
X4
b c
b c
Super flat cable
connection cable
c
X4
a
Solar parallel
d
X2
