5.2 Functions & Adjustments of Nozzles
There are two nozzles on the cleaner, one of them opens when the
other closes. Water flows out through the open nozzle to thrust the
cleaner to move forward. Adjust the nozzle by turning it to control the
moving route.
a. Settings of nozzle angle and moving route
Sketch: the nozzles of the cleaner are marked with angles (0°-40°).
The cleaner moves in an approximately straight line when the nozzle
angle is 0°. The cleaner moves in a more curved line at a larger angle
from 0°-40°.
b. Recommended three nozzle settings
Setting One: default setting: 0°—20°, for most of the pools.
Nozzle Angle
Moving Route
