FAULT GUIDE & TROUBLE SHOOTING
The charger includes many safety features to protect your electric vehicle, a fault is indicated by illumination of the Red indicator.
Fault State
RCD leakage
Over current
Ground fault
O/U V fault
Relay fault
CP Error
O/T protection
Diode LOSS
Reset/clear fault instructions
1. Unplug charging cable from the vehicle.
2. Unplug (or turn off) charging cable from the wall socket.
3. Keep unplugged for 30 seconds.
4. Repeat connection process.
If the faults are not reset, the charging cable may be fault. Please contact the retailer or Masterplug via our help desk
support team – 03300 249 279 / technical.support@masterplug.com
Technical
Rated Current/Voltage/Frequency: 16A/220-240V/50Hz
Output: 3.6kW Max
Rated Residual Operating Current: IΔn: 30mA, 6mA DC
Operating Temperature: -25°C to +40°C
IP Rating: IP66(Control Box)
Standards: EN 62752; EN 61851-1
Care
Masterplug recommend the use of a soft dry or slightly damp cloth periodically to clean the cable and charger body.
Do not use cleaning agents.
Batch Code Explanation
yyWxx Manufacturing date code, year of manufacture (yy) and week of manufacture (Wxx).

Environmental Protection

This symbol is known as the "Crossed-out Wheelie Bin Symbol". When this symbol is marked on a product or battery, it means
that it should not be disposed of with your general household waste. Some chemicals contained within electrical/electronic
products or batteries can be harmful to health and the environment. Only dispose of electrical/electronic/battery items in separate
collection schemes, which cater for the recovery and recycling of materials contained within. Your co-operation is vital to ensure
the success of these schemes and for the protection of the environment.
Address/Helpline
(UK) Luceco PLC Stafford Park 1 Telford TF3 3BD ENGLAND. (EU) Luceco SE C/ Bobinadora 1-5 08302 Mataró SPAIN
If you have further technical assistance you can get in touch with our Technical Helpline on:
03300 249 279 / technical.support@masterplug.com
Mode 2 EV Charger DC.01.2025
Indicator status
Single red flash at regular intervals
Two red flashes twice at regular intervals
Three red flashes at regular intervals
Four red flashes at regular intervals
Five red flashes at regular intervals
Six red flashes at regular intervals
Eight red flashes at regular intervals
Nine red flashes at regular intervals
Remark
Leakage fault
Over current protection fault
Ungrounded fault
Over/under voltage protection fault
Relay sticking or relay failure
Control pilot signal fault
Over temperature protection fault
Diode loss failure
