9.2

Lubrication

From time to time, apply a drop of oil to the thread of the lock screw.

10 TECHNICAL DATA

Rated voltage
Rated frequency
Rated power
Rotation speed
Blade diameter
Cable length
Max. cutting depth
Maximum cutting capacity 45°
Carbon brush motor
Bore size
Adjustable angle
Number of teeth
Safety guard
Second handle type

11 NOISE

Noise emission values measured according to relevant standard. (K=3)
Acoustic pressure level LpA
Acoustic power level LwA
ATTENTION! Wear hearing protection when sound pressure is over 85
dB(A).
aw (Vibration)
▪
The specified total vibration values and the specified noise emission values were
measured according to a standardised test method and can be used to compare one
power tool with another.
The vibration emission and the sound emission during actual use of the
power tool can differ from the declared emission value depending on the
ways in which the tool is used.
Be sure to identify safety measures to protect the operator that are based
on an estimation of exposure in the actual conditions of use (taking
account of all parts of the operating cycle such as the times when the tool
is switched off and when it is running idle in addition to the trigger time).

12 SERVICE DEPARTMENT

▪
Damaged switches must be replaced by our after-sales service department.
▪
If the connecting cable (or mains plug) is damaged, it must be replaced by a particular
connecting cable which is available from our service department. Replacement of the
connecting cable must only be carried out by our service department (see last page) or by
a qualified person (qualified electrician).
Copyright © 2024 VARO
POWC2020
220-240 V
50 Hz
800W
4500min
140 mm
2 m
45 mm
30 mm
Yes
16mm
Yes
18 T
Yes
Guide handle
92 dB(A)
103 dB(A)
3.7m/s²
P a g e | 8
EN
-1
K = 1.5 m/s²
