(328IO) MODEL ZS6220 & ZS6230 OZONE & SALTWATER SYSTEM ENGLISH 7.5" X 10.3" PANTONE 295U 07/05/2024
Before assembling your product, please take a few minutes to check the contents
1
2
5
6
4
11
12
NOTE: Drawings for illustration purpose only. Actual product may vary. Not to scale.
REF. NO.
1 ADAPTOR A WITH THREADED COLLAR
2 L-SHAPE O-RING
3 SCREW
4 TITANIUM ELECTRODE NUT
TITANIUM ELECTRODE
5
6 O-RING ON TITANIUM PLATES
7 FLOW SENSOR
8 CONNECTOR HOSE WITH THREADED FITTINGS
ELECTROLYTIC CELL HOUSING
9
10 CONTROL STATION
11 CELL COVER
12 TEST STRIPS
When ordering parts, be sure to quote the model number and part numbers.
SAVE THESE INSTRUCTIONS
PARTS REFERENCE
and become familiar with all the parts.
7
3
9
DESCRIPTION
English
8
2
10
SPARE
QTY.
PART NO.
1 10849
2 11228
2 11519
1 11432
1 11374
1 11515
1 11460
1 10720
1 12663
1 12662
2 11131
1 19635
