SHOWER TOILET 540 / 540
3. Open the lid, use tool to take out the decorative
cap, use screwdrive to take out screw (save the
screw), take out the electronic seat with cover
and put it in a clean place.
5. Keep the product in horizontal
position by Spirit level.
Put plastic plug, stainless base into
the screw rod and tighten the nut;
then the ball valve is connected to
outlet-water hose.
Press flush button to discharge the
drain first.
560 / 560
Pro -
4. Insert the water drain hose through the back of the
Drain hole
Acoustic protection mat
Flush hole
Screw rod 60mm to wall
Outlet hose
Screw rod
Plastic plug
Stainless base
Nut
Water-outlet hose
Pro
toilet and adjust the position so that the flush and
drain openings of the toilet are exactly aligned.
Move the toilet against the wall in the direction
of the arrow until it locks into place.
Acoustic protection mat
Outlet hose
Spirit level
Decorative cap
Screw
Fixing hole
Fixed hole
