Technical Data

Measurement Principle
Materials with vacuum
contact
Measuring Range
Max. Overload
Accuracy
Repeatability
Response Time
Power Supply
Electrical Connection
Power Consumption
Operating Temperature
Storage Temperature
Bakeout Temperature
Output Signal
Vacuum Connection
Protection Class
Weight
VSP63-de-120207
Heat conduction (impuls Pirani), depending on gas type
stainl. steel 1.4307, Tungsten, Nickel, glass
-4
1000 - 1,0x10 mbar (750 - 1,0x10
4 bar abs.
1000 - 20mbar: ca. 30 % from reading
20 - 0,001mbar: 10 % from reading
< 0,001mbar: < factor 2 from reading
20 – 0.001mbar: 2% from reading
< 200 ms
15 – 30 VDC
Type Hirschmann, 6pin, male, lockable
max. 1.0 W with 24 V supply voltage
o
5...60 C
o
-20...+70 C
o
80 C at the flange
0 – 10 VDC, load > 10 Ω
range 1.5 – 8.5 VDC, logarithmic (1V/decade)
VSP63MV: small flange DN16 ISO KF
VSP63MVSW: DN16KF with hose nozzle 9,5mm
VSP63MVCF: conflat flange DN16 CF
IP 40
120g
-4
Torr) abs.
