Key assignment for the inner LEDs:
The key assignment for the inner LEDs is done under the menu item "reno". Then select the
desired button assignment on the remote control from b-01 to b-08 and press "Enter".
You can then select and confirm the corresponding color for the buttons from
Co 0 to Co 7 or the corresponding program from Pr 1 to Pr 4.
Code
0
1
2
3
4
5
6
7
Pr 1
Pr 2
Pr 3
Pr 4
Key assignment for the outer LEDs:
The key assignment for the outer LEDs is done under the menu item "AUHC".
Then select the desired button assignment on the remote control from b-01 to b-08 and press
"Enter". Select the appropriate color from AU00 to AU07 for the 8 buttons.
Code
AU00
AU01
AU02
AU03
AU04
AU05
AU06
AU07
Function
Fog
Fog + Red
Fog + Yellow (Red +Green)
Fog + Green
Fog + Cyan (Green + Blue)
Fog + Blue
Fog + Magenta (Blue + Red)
Fog + White
Fog + RGB Fade
Fog + 7 Colors Fade
Fog + RGB Scroll
Fog+ 7 Colors Scroll
Function
LED off
Red
Yellow
Green
Cyan
Blue
Magenta
White
