ISRI NTS2-E Bedienungsanleitung Seite 20

For your safety, and for the safety of other drivers, the seat is only allowed to be adjusted when the vehicle
is stationary and the hand brake is pulled.
Card Reader
LED Green
LED Orange
7018587/Rev.23.04.2018
3
Tilt Adjustment / 6
Horizontal Slides
Card Reader/ Memory Control
3
4
The ISRI driver card can save 3 seat positions and is readable from all
ISRI NTS2-E seats with card reader.
The seat position (I) is defined together with a doctor as the optimal
adjusted seat position and is saved on the driver card as the starting
position.
This position (I) is not changable by the driver.
Transfer seat positions from the driver card to the seat:
Hold driver card at the card reader untill the green LED lights up. The datas
will transfered from the driver card to the seat.
The seat positions (I, II, III) that are saved on the driver card, will allocated
to the seat memory positions (I, II, III). The seat moves automatically to the
seat position (I).
Note: Only when previously switched on / off the ignition or a another driver
card was used. The automatic adjustment can be canceled by pressing
any button.
Save current seat position:
Press memory button (II) or (III) so long till a signal tone is hearable. The
current seat position is saved at the seat now. The card reader indicates
now by the orange LED, that new datas are available. For transfering the
datas to the driver card, hold driver card at the card reader again till green
LED lights up. The seat adjustments for backrest, horizontal slides, tilt- and
height adjustment are saved on the card now.
Memory position 1
Memory position 2, 3
Explanation of LED lamps:
LED green lights up:
LED orange lights up:
LED green flashes:
INSTRUCTION MANUAL ISRI NTS2-E
5
Exit Position
4
Memory Control Buttons
I II
III
7 Height Adjustment /
Horizontal Slides
Optimal seat position. Not over-writable by driver.
Individual seat position. Can be changed by driver.
Card detected / Data transfer successfully.
There are new datas, which can be transfered to
the driver card.
No suitable driver card / Card invalid.
8
Backrest Adjustment
20
