Tutorial - Quick Start to Use SE323:
(1) Recording real time data in waveform.
(a) Power on the Sound Level Meter first and
connect it to a PC USB port with the cable.
(b) Start SE323 program.
(c) If the connection is successful, the panel will
display the same value as the Sound Level
Meter. If fail to connect the meter with PC, it will
display "No Connection" on the panel window
in SE323.
(d) When the connection is successful, click
data and there will be a waveform on the Real Time Graph Window.
(e) Click
(2) How to save the recorded real time data to a file?
(a) Click the graph window you want to save and the graph window will
become active, then choose File | Save from main menu or click
the tool bar.
(b) There will be a save dialog window for you to choose the file name and
file type to save. There are three types of file name you can choose, binary
file(*.ghf), text file(*.txt) and EXCEL format file(*.csv). The *.ghf file use much
fewer disk space to save the data than the other two file format, but it can
only be used in SE323. Text file can be opened by SE323 and any other
word processor program like word, notepad etc. EXCEL format file can be
opened by SE323 and Microsoft EXCEL.
to start recording.
to start recording real time
32
Sound Level Meter
from
