Pyle PPHP109WMUEU Benutzerhandbuch Seite 4

PPHP1299WU.5:
1000 Watt, 12" Subwoofer Wireless & Portable BT PA Speaker
Features:
Dual High-Powered Loudspeaker PA Systems
Rugged, Durable & Reliable Sound
Wireless BT Music Streaming Ability
Speaker System: 12" Woofer, 1.34" Tweeter
Compression Driver with Titanium Diaphragm
2-Way Full Range Audio Projection
XLR Microphone Input
¼" Jack Microphone Input
RCA line input (R+L), Aux (3.5mm) line input
¼" Jack Line Out
Two UHF Wireless
Connect and Stream Audio from External Devices
USB Flash Drive & SD Memory Card Readers
Digital LCD Display
Rear Panel Rotary Dial & Button Control Center
Mic Volume, Echo Volume, Master Volume, Bass, Treble Adjustable
Integrated Carry Handles
35mm Speaker Stand Mount Compatible
Heavy-Duty Engineered ABS Housing
What's in the Box:
PA Speaker
(2) Wireless Hand held Microphone
Power Cable
Remote Control
6
www.PyleUSA.com
MP3 Audio Recording Ability:
It's Easy: One Button Record Activation
Record Audio as Streamed through the Speaker System
Ability to Record Vocals via Microphone
Can Also Record Audio via Line & Aux Inputs
Records to USB Flash & SD Memory Card
Easy Transfer to PC & Mac
Technical Specs:
Power Output: 1000 Watt MAX
Impedance: 4 Ohm
T.H.D.: <1%
Magnet: 40 oz.
Sensitivity: 92dB (+/-2dB)
Mic Input Level: <1 SmV
Line Input/Output Level: >250mV
Frequency Response: 50-1 SkHz
Digital Audio File Compatibility: MP3, WMA
Maximum SD/USB Flash Memory Support: 32GB
Power Supply: AC 110/220V, 50/60Hz
Product Dimensions (L x W x H): 37 x 31 x 58 cm/14.7" x 12.2" x 22.8"
inches
7
www.PyleUSA.com
