Box contents
• Left rear surround speaker
• Right rear surround speaker
• EU AC power cable (2 pcs)
• UK AC power cable (2 pcs)
• Speaker wall-mount fixings
• User manual
• Warranty card
Controls
Rear surround speaker
(Refer to
1 on page 1)
1. PAIR indicator.
2.
button – Please refer to section "Speaker pairing".
3. Wall mount / screw hook.
4. AC IN power input.
Placement and mounting
Placement
To enjoy immersive audio from your Sharp Q wireless rear surround
speakers, place the speakers behind your preferred listening position,
ideally at ear level. The speakers can be placed on speaker stands,
furniture or you can mount the speakers to a suitable wall.
NOTE:
ū Refer to the rating label on the back of each speaker to check if it is the
left or right speaker.
is for the left speaker and
speaker.
A Place the speakers upright on the speaker stands/furniture at ear
level behind your preferred listening position. (Refer to
page 1)
B Place the speakers on the wall using wall mounts at ear level behind
your preferred listening position. (Refer to
IMPORTANT NOTES:
ū Do not mount the speakers too close to the ceiling. The minimum
distance between the speaker and the ceiling should be 50cm.
ū The height effect won't be noticeable in rooms with very high ceilings.
ū Installation must be carried out by qualified personnel only. Incorrect
assembly can result in severe personal injury and property damage (if
you intend to install this product yourself, you must check for installations
such as electrical wiring and plumbing that may be buried inside the
wall). It is the installer's responsibility to verify that the wall will safely
support the total load of the unit and wall brackets.
ū Additional tools (not included) are required for the installation.
ū Do not over-tighten screws.
ū Keep this user manual for future reference.
ū Use an electronic stud finder to check the wall type before drilling and
mounting.
Your wall mount preference will determine the type of wall mounting
option you use on the speaker.
A: Using the wall mount hole
Refer to the table below and
is used.
Depth of wall bracket plate (mm)
NOTES:
ū The depth of the screw hole on the speaker is 17.4 mm
ū The correct screw type to use is:
Imperial: 1/4-20 inch
Metric: 6.35 mm diameter, 1.27 mm thread pitch
ū When mounting to the wall, remove the plastic stand.
B: Using the slot and hook mount
Wall mount the speakers using the slot and hook mount. (Refer to
3 on page 1)
Ensure the screw used will fit into the wall mount hook securely.
NOTES:
ū When using the slot and hook mount, ensure that the speakers are not
free to move around freely.
ū When mounting to the wall, remove the plastic stand.
Initial set up
Connect to power
Risk of product damage! Ensure that the power supply voltage
corresponds to the voltage printed on the back of the unit.
Connect the power cable to the AC IN socket of the unit and then into
is for the right
a mains socket.
Speaker pairing
4 on
Manual pairing
5 on page 1)
You will need to manually pair the rear surround speakers to the
soundbar before you can use them with the soundbar.
1. Ensure that all the cables are securely connected and the soundbar
is in STANDBY.
2. Press and hold the
seconds. The speaker will enter pairing mode and the
will flash quickly.
3. Press the
switch the soundbar on.
4. Press the
directional control on the remote control to highlight <WLPAIR>.
Press
5. When the speaker is paired with the main unit, the
will be solid and the soundbar will display <PAIRED>.
6. If the
soundbar will display <SPK NC>.
Unplug the power cable from the speaker and then reconnect the
power cable after 4 minutes. Repeat steps 1 ~ 4.
NOTE:
ū If the wireless connection fails again, check if there is conflict or strong
interference (for example, interference from an electronic device) around
2 on page 1. Ensure the correct screw
A:
Length of screw required
2-6mm
button on the rear of the speaker for 3
button on the soundbar or on the remote control to
button on the remote control, then use the
and wait for 5 seconds.
indicator blinks, the wireless connection has failed. The
EN
B:
MIN~MAX (mm)
14 mm
indicator
Indicator
