EN
1 INTRODUCTION
1.1 PURPOSE
This machine is designed for cutting branches and limbs
of a diameter determined by the cutting length of the
guide bar. It is not designed for felling trees or cutting
logs. It is only designed to cut wood.
1.2 OVERVIEW
Figure 1-14.
Scabbard
1
Guard
2
Front handle
3
Lock-out button
4
Trigger
5
Rear handle
6
Chain cover
7
Chain tension knob
8
Bucking spikes
9
2 GENERAL SAFETY
WARNINGS
Read all safety warnings, instructions, illustrations
and specifications provided with this machine.
Failure to follow all instructions listed below may result
in electric shock, fire and/or serious injury.
Save all warnings and instructions for future
reference.
The term "power tool" in the warnings refers to your
mains-operated (corded) power tool or battery-operated
(cordless) power tool.
3 ASSEMBLY
This section describes how to assemble and adjust the
product.
CAREFULLY READ AND UNDERSTAND THE
SAFETY CHAPTER AND THE ASSEMBLY
INSTRUCTIONS BEFORE YOU ASSEMBLE THE
PRODUCT.
3.1 ADD BAR AND CHAIN OIL
Figure 2.
Use only bar and chain oil.
10 Chain
11 Guide bar
12 Handle of chain
tension knob
13 Sprocket
14 Chain tension pin
hole
15 Bolt for saw chain
tension
WARNING
WARNING
IMPORTANT
English
The machine comes from the factory without bar and
chain oil.
1. Switch off the machine.
2. Remove the battery pack and position the machine
on a level surface with the chain cover facing
upwards.
3. Clean the guide bar and saw chain with a soft brush
or solvent.
4. Apply oil in the area between the guide bar and saw
chain.
5. Install the battery and switch on the machine.
6. The oil is evenly dispersed on the chain.
Do not use dirty, used or contaminated oil. Damage
can occur to the bar or chain.
3.2 INSTALL THE BATTERY PACK
Figure 1.
• If the battery pack or charger is damaged, replace
the battery pack or the charger.
• Stop the machine and wait until the motor stops
before you install or remove the battery pack.
• Read, understand, and follow the instructions in
the battery and charger manual.
1. Align the lift ribs on the battery pack with the
grooves in the battery compartment.
2. Push the battery pack into the battery compartment
until the battery pack locks into place.
3. When you hear a click, the battery pack is installed.
3.3 REMOVE THE BATTERY PACK
Figure 1.
1. Push and hold the battery release button.
2. Remove the battery pack from the machine.
4 OPERATION
This section describes how to operate the product.
CAREFULLY READ AND UNDERSTAND
THE SAFETY CHAPTER AND OPERATION
INSTRUCTIONS BEFORE YOU OPERATE THE
PRODUCT.
4
NOTE
IMPORTANT
WARNING
WARNING
