03 PRODUCT IN OPERATION
ASSEMBLY
The Actimo Home rollator is delivered pre-assembled in a cardbo-
®
ard box. Check the packaging and contents to ensure that they are
intact and complete.
You will receive the following individual parts
1 x Actimo Home pre-assembled
®
1. Remove the rollator and hold it by the handle. Unfold the rollator
by pushing the upper cross strut downwards. Check the lower
strut to ensure that the folding mechanism is fully unfolded.
2. To adjust the handle height,
loosen the two wing screws
on the frame by turning them
anti-clockwise. Remove the
two screws one after the ot-
her while holding the handle
firmly. Adjust the height and
reinsert the two screws from
the inside through the holes
in the frame. Tighten both
screws clockwise.
3. To attach the net, open the Velcro fasteners, place them around
the black frame and close them. Insert the shelf and carefully
press the tray onto the frame.
4. To fold the rollator, remove the
tray and the net. Hold the rolla-
tor by the handle with the brake
applied and pull the lower black
strut upwards.
12 | REHAFORUM MEDICAL
| 1 x tray | 1 x shopping net
USING THE BRAKES AND PARKING BRAKES
• To slow down or stop the rollator briefly, pull the brake lever
upwards in the centre or with both hands. Do this until you have
reached the desired speed or have stopped.
• To lock the parking brake, press the brake lever downwards until
it engages.
• To release the parking brake, pull the brake lever upwards so that
the lock is released.
• The braking effect can be adjusted directly on the brake bracket
or on the Bowden cable.
