SCOPE OF DELIVERY
The following components and accessories are included in the scope of delivery
• Actimo ® Home
• Tray
• Shopping net
• Instructions for use
STRUCTURE OF THE ACTIMO® HOME
13
1. handle
2.
brake handle
3. bar with handle / brake
4. brake adjustment screw
5.
wing screw for height
adjustment
1
2
4
9
14
6. tray
7.
velcro fasteners net
8. net
9. brake cable
10.
frame
11. tilting aid
3
5
6
8
11
12
15
12. type plate / warning
notice
13. brake block
14. rear wheel
15.
front wheel (swivelling
wheel)
