Czas ładowania
akumulatora 2Ah
Czas
ładowania
akumulatora 4Ah
Czas
ładowania
akumulatora 6Ah
Czas
ładowania
akumulatora 8Ah
Klasa ochronności
Masa
Rok produkcji
OCHRONA ŚRODOWISKA
Produktów zasilanych elektrycznie nie należy wyrzucać wraz z
domowymi odpadkami, lecz oddać je do utylizacji w odpowiednich
zakładach. Informacji na temat utylizacji udzieli sprzedawca produktu
lub miejscowe władze. Zużyty sprzęt elektryczny i elektroniczny
zawiera substancje nieobojętne dla środowiska naturalnego. Sprzęt
nie poddany recyclingowi stanowi potencjalne zagrożenie dla
środowiska i zdrowia ludzi.
„GTX Poland Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa z
siedzibą w Warszawie, ul. Pograniczna 2/4 (dalej: „GTX Poland ") informuje, iż
wszelkie prawa autorskie do treści niniejszej instrukcji (dalej: „Instrukcja"), w tym m.in.
jej tekstu, zamieszczonych fotografii, schematów, rysunków, a także jej kompozycji,
należą wyłącznie do GTX Poland i podlegają ochronie prawnej zgodnie z ustawą z
dnia 4 lutego 1994 roku, o prawie autorskim i prawach pokrewnych (tj. Dz. U. 2006
Nr 90 Poz 631 z późn. zm.). Kopiowanie, przetwarzanie, publikowanie,
modyfikowanie w celach komercyjnych całości Instrukcji jak i poszczególnych jej
elementów, bez zgody GTX Poland wyrażonej na piśmie, jest surowo zabronione i
może spowodować pociągnięcie do odpowiedzialności cywilnej i karnej.
GWARANCJA I SERWIS
Warunki gwarancji oraz opis postępowania w przypadku
reklamacji zawarte są w załączonej Karcie Gwarancyjnej.
Serwis Centralny GTX Service Sp. z o.o. Sp.k.
ul. Pograniczna 2/4 tel. +48 22 364 53 50 02-285 Warszawa e-mail
bok@gtxservice.com
Sieć
Punktów
Serwisowych
pogwarancyjnych dostępna na platformie internetowej gtxservice.com
Zeskanuj QR kod i wejdź na gtxservice.com
ENGLISH (EN)
TRANSLATION OF THE ORIGINAL INSTRUCTIONS
58G002-1, 58G085-1
NOTE: READ THIS MANUAL CAREFULLY BEFORE USING THE
POWER TOOL AND KEEP IT FOR FUTURE REFERENCE.
Safety instructions for the battery charger
• This equipment is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities
or lack of experience or familiarity with the equipment, unless
supervised or in accordance with the instructions for use given
by those responsible for safety.
• Keep an eye on children so that they do not play with the
equipment.
• The charger must not be exposed to moisture or water. The
ingress of water into the charger increases the risk of shock. The
charger may only be used indoors in dry rooms.
• Unplug the charger from the mains before carrying out any
maintenance or cleaning.
• Do not use the charger placed on a flammable surface (e.g.
paper, textiles) or in the vicinity of flammable substances. Due
to the charger's temperature increase during the charging
process, there is a danger of fire.
• Check the condition of the charger, cable and plug each time
before use. If damage is found - do not use the charger. Do not
attempt to disassemble the charger. Refer all repairs to an
authorised service workshop. Improper installation of the
charger may result in a risk of electric shock or fire.
50 min
45 min
100 min
90 min
150 min
135 min
200 min
180 min
II
II
0,300 kg
0,700 kg
2024
2024
do
napraw
gwarancyjnych
LOADER
• Children and physically, emotionally or mentally handicapped
persons, as well as other persons whose experience or
knowledge is insufficient to operate the charger with all safety
precautions, should not operate the charger without the
supervision of a responsible person. Otherwise there is a danger
that the device will be mishandled resulting in injury.
• When the charger is not in use, it should be disconnected from
the mains.
• All charging instructions must be followed, and the battery must
not be charged at a temperature outside the range specified in
the rating table in the operating instructions. Charging incorrectly
or at temperatures outside the specified range can damage the
battery and increase the risk of fire.
Repair:
• A defective charger must not be repaired. Repairs to the
charger are only permitted by the manufacturer or an authorised
service centre.
• The used charger should be taken to a disposal centre for this
type of waste.
Explanation of the used pictograms
1.Read the operating instructions, observe the warnings and safety
conditions contained therein!
2.Protect the charger from moisture and rain.
3.Second class of protection.
4.Charger designed for indoor dry operation.
5.Recycling.
6.Selective collection.
CONSTRUCTION AND APPLICATION
The 58G002-1 and 58G085-1 chargers are dedicated exclusively to
charging lithium-ion (Li-Ion) batteries of the Energy+ system.
i
The chargers are powered from the domestic 230V mains, making
them stable charging devices.
An electronic circuit with automatic current control protects the
battery from overcharging and overheating. Battery charging is
automatically interrupted when the battery reaches full charge.
INTENDED USE
The 58G085-1 is a dual charger, which means that it can be used
to charge 1 or 2 batteries. It is prohibited to place batteries
(rechargeable batteries) other than those recommended in the
charger. Any use of the charger not in accordance with the above
description may result in damage to the charger and may lead to
electrical short circuit, fire ignition, electric shock, etc.
When charging the batteries on the 58G085-1 charger, each battery
has its own independent indication (LEDs) of the charging process.
The previously charged battery can be removed from the charger
while the other battery continues to be charged. This is the case
when the batteries placed in the charger are of different discharges
or capacities.
DESCRIPTION OF THE GRAPHIC PAGES
The numbering below refers to the components of the unit shown
on the graphic pages of this manual:
Fig A, B.
1.Battery socket
2.Information on the charging rate
3.Charging status LEDs
* There may be differences between the drawing and the product.
CHARGING PROCESS
• When the charger is plugged into a mains socket (230 V AC),
the green LED (3) on the charger lights up to indicate that the
voltage is connected.
• Place the battery in the charging socket (1)
• When the battery pack is placed in the charger, the red LED (3)
on the charger will illuminate to indicate that the battery is in the
process of being charged.
• When the battery is charged, the LED (3) on the charger lights
up green.
5
