4. Band and mode
Band and Mode
EGSM900
DCS1800
WCDMA 900/2100
LTE 1/3/7/8/20/28/38/40/68
WiFi 2.4 GHz
Bluetooth 2.4 GHz
WiFi 5.1-5.7 GHz
WiFi 5.8 GHz
NFC 13.56 MHz
n1/n3/n7/n8/n20/n28/n38/n40/n77/n78 (FR1)
The use of WLAN band is restricted to indoor use only. This restriction will be applied in all
EU member states.
AT
BE
BG
FI
FR
HR
MT
NL
NO
5. Repair
Repairs are to be conducted by Pepperl+Fuchs or by personnel or service centers authori-
zed by Pepperl+Fuchs only, due to the safety of the device needs to be tested after repairs
are implemented. The actual repair report sheet can be downloaded from the service area
at www.pepperl-fuchs.com.
6. Inserting the SIM/USIM card (LTE/WWAN model only) and microSD card
1. Remove the Ex-Protective Cover of the device.
2. Pull out the tray gently from the tray slot.
3. Place the SIM or USIM card on the tray with the gold-coloured contacts facing
downwards.
4. Gently press the SIM or USIM card into the tray to secure it.
5. Attach the Ex-Protective Cover.
See also Picture Page 20
CH
CY
CZ
HU
IE
IS
PL
PT
RO
Output Power
33 dBm
30 dBm
24 dBm
23 dBm
20 dBm
20 dBm
24 dBm
25 dBm
42 dBuA/m at 10 m
23 dBm
DE
DK
EE
IT
LI
LT
SE
SI
SK
5
ES
EL
LU
LV
TR
UK(NI)
GB
EN
