Software settings
增高脚的使用方法
LightBurn Y-axis maximum travel value modification steps
1.Run the LightBurn, get a com port connected, "Ready"displayed at
the bar marked by number 2 indicates connection succeed.
3.Expand output, modify the value of Y Steps per mm($101) to 100 and
that of Y max travel(mm)($131) to 800, click Write then OK to save the
modification.
Note: When the conveyor is not
used, please restore Y Steps per
mm($101) and Y Max travel($131)
to the default values, i.e. 133.33 and
300.
2.Go to Machine Settings under Edit nenu.
4.Enter " $drawer_alarm/enable=Off" in command input bar of
console and execute it，disable the limit switches of the drawer
tray accordingly
