Roger Technology EDGE1 Anweisungen Und Hinweise Für Den Installateur Seite 74

15
TEST
x5 s
INFO mode may be used to view certain parameters measured by the EDGE1 controller.
Press and hold the TEST button for 5 seconds from the "View command signals and safety devices" mode with the motor
stationary. The control unit displays the following parameters and the corresponding measured values in sequence:
Parameter Function
.
View for 3 s
Displays the position of MOTOR 1 / MOTOR 2, expressed in revolutions and relative to total length, at the time
of the test.
View total length of MOTOR 1/ MOTOR 2 programmed travel , in motor revolutions.
View MOTOR 1 /MOTOR 2 speed, in revolutions per minute (rPM).
View current absorption of MOTOR 1/MOTOR 2, in Amperes (e.g.: 001.1 = 1,1 A .... 016.5 = 16,5 A).
If the MOTOR 1 / MOTOR 2 is stationary, the current absorption value is 0. Activate a command function to test
current absorption.
System OK indicator. To check for overloading (e.g.: too many utilities connected to 24 V output) or if the mains
voltage is too low, compare the parameters read with values indicated as follows with the motor stationary:
mains voltage= 230V~ (nominal), bUS=
mains voltage= 207V~ (-10%), bUS=
mains voltage= 253V~ (+10%), bUS=
Display current, expressed in Amperes, used to compensate for strain detected by MOTOR 1 / MOTOR 2 due,
for example, to low external temperatures (e.g.: 0 = 0 A ... 4 = +3 A). At the beginning of a manoeuvre from the
completely open or completely closed position, if the control unit detects a strain higher than the value stored
in its memory during the travel acquisition cycle, the controller automatically increases the current delivered to
MOTOR 1 / MOTOR 2.
Display current threshold, expressed in Amperes, at which the obstacle detection function (crush prevention)
of MOTOR 1 / MOTOR 2 is triggered. This value is calculated automatically by the controller in relation to the
settings of parameters
For the motor to function correctly,
Indicates time taken by motor to detect an obstacle, as set with parameter
E.g. 1.000 = 1 s / 0.120 = 0.12 s (120 ms). Ensure that the manoeuvre time is more than 0.3 s.
MOTOR 1 / MOTOR 2 status OK indicator. In normal conditions, this value is less than 500. If the value exceeds
2000, the controller disables the motor. A value exceeding 500 indicates that the characteristics of the connec-
tion cable are inadequate for the installation or that the connection cable is too long or of inadequate cross
section, or may indicate an electrical fault of the brushless motor.
If the control unit is capable of identifying the position of the gate leaf when the test is conducted, the following
is shown on the display:
Indicates the state of the automation system (open/closed).
Displays the number of hours remaining before the maintenance alarm is activated. The number is preceded by
a point. Example: -1234 hours remaining until maintenance alarm = .1234
• Pressing
as 0.0.0.0. .
• Pressing
Displays 00= motor brake not active;
on both motors;
• If only one motor is connected to the control unit, the parameters relative to "MOTOR 1" only are displayed.
• Use the + / - buttons to scroll through the parameters. When the last parameter in the sequence is reached, press
the - button to return through the previous parameters.
• In INFO mode, the automation system may be activated to test operation in real time.
• The two motors may be controlled independently in OPERATOR PRESENT mode, ignoring the position data request
74
, and
position known, normal operation.
LEAF 1 position unknown, position recovery in progress.
LEAF 2 position unknown, position recovery in progress.
positions of both leaves unknown, position recovery in progress.
automation system opening (motor active).
automation system closing (motor active).
automation system completely open (motor not actives).
automation system completely closed (motor not actives).
mains voltage too low or overload.
motors overcurrent.
(DOWN arrow): view number of hours of last maintenance service. The first service is indicated
(UP arrow): return to remaining hours display.
= brake function not available.
.
.
.
.
must always be lower than the value
=brake active on motor 1;
TEST
TO QUIT
...
THE INFO MODE
.
/ , in seconds.
=brake active on motor 2; = brake active
1 click
