Tv out hdmi arc
Connect your HDMI cable to your TV and the out labeled ARC. The HDMI cable hast to be on Version 1.4 or higher.
Press „TV" on your remote control repeatedly, until TV(ARC) is displayed. The Audio back channel is now activa-
ted. Through this, the TV's sound is transmitted to the CVR-200 AV and you can enjoy your media through the
device. In disc mode or USB 2 mode, the menu and further settings/information will be isplayed on the device.
TV in hdmi
The three rear HDMI inputs are used to connect TV's, video game consoles or similar media with an HDMI out.
The display then shows the current channel mode (e.g. Multi 5.1), the sampling rate and the current volume.
The loudspeaker outputs
At its back, the CVR-200 AV is equipped with seven high-quality gold-plated terminal pairs for the connection of
loudspeaker cables. Cables can be connected either via banana plugs mounted on the cables (plug-in moun-
ting) or via the screwable terminal heads with the stripped loudspeaker cable (screw mounting).
The line-in connector
The line-in connector located behind the magnetic cover at the front of the CVR-200 AV processes electrical
high-level audio signals in analogue form. This connector is suitable for all external devices with analogue audio
output, like media players, iPod®, smartphones etc. (connection over headphone output). For the connection,
please consult the operating instruction of the external device. A suitable 3.5 mm cable shall be bought in an
accessory shop.
The headphone connection
The headphone jack of the CVR-200 AV, located behind the magnetic cover on the front, allows you to connect
any commercially available headphone with 6.3 mm jack plug. A 3.5 mm jack adapter for smaller headphones
can be obtained from an accessory shop.
66
