NOTICE
• Do not short circuit the battery terminals.
• Never attempt to remove the casing from the battery pack.
• Never store the battery in unsafe surroundings, as a short may cause an explosion.
• Do not put the battery in a hot environment or throw it into a fire, as it may cause an explosion.
3. PREPARATION
3.1 Installing / Removing the Battery
Installing the Battery Pack
(1) Position the battery pack over the back of the radio.
(2) Engage the battery pack into the radio until battery pack is fully seated into the radio housing.
(3) Tighten the screws using a coin or at object to secure the battery pack to the radio. Do not overtighten.
To Remove Battery Pack from Radio
(1) Loosen the screws on the back of the battery pack.
(2) Lift the bottom of the battery pack slightly to remove it from the radio housing.
(3) Pull the battery pack out of the radio housing.
NOTE:
The Li-ON battery pack can also be charged in the battery charger.
3.2 Installing / Removing the Antenna
(1) Installing the Antenna: Screw the antenna into the connector on the top of the transceiver by holding the antenna at its base and turning it clockwise until
secure.
(2) Removing the Antenna: Turn the antenna counter-clockwise to remove it.
3.3 Installing Additional Speaker/Microphone (Optional)
Pry open the rubber MIC-Headset jack cover and then insert the Speaker / Microphone plug into the double jack.
