R&S Scope Rider RTH
2.3

Powering On/Off

► Press the POWER key to switch the instrument on or off.
The key blinks and turns green after a few seconds.
Table 2-1: Colors of the Power key
Green
Blue
Orange (yellow)
If you do not use the instrument for a longer time, the battery gets exhausted.
When you connect the power supply and switch on the instrument with exhausted
battery, it takes a few minutes until the instrument can start.
2.4

Using the Tilt Stand

The R&S RTH has a tilt stand for proper handling while the scope is placed on a
table.
► Pull the tilt stand as shown below.
Getting Started 1326.1561.02 ─ 05
All manuals and user guides at all-guidesbox.com
Power is on
Charging the battery, power is off
Battery is fully charged, power adapter is connected, power is off
Preparing for Use
Using the Tilt Stand
19
