ATR833S / P/N 833S-(Cxxx)-(Cxxx)
Bedienung und Einbau
4.7.3
Verkabelung mit Kabelsatz BSKS833SD
4.7.3.1 Übersicht
BU 1
D-SUB DB-25
female
PIN 5
PIN 18
PIN 14
PIN 17
PIN 20
PIN 21
PIN 8
PIN 19
PIN 6
PIN 15
PIN 2
PIN 3
PIN 1
PIN 16
PIN 4
PIN 7
PIN 22
PIN 9
PIN 24
PIN 12
PIN 11
PIN 13
PIN 25
Do not connect
PIN 23
Do not connect
PIN 10
41
20 cm
PTT 1 (right)
yellow
GND
blue
PTT 0 (left)
orange
GND
blue
280 cm
MIC 1 (right)
PTT 1 (right)
Head 1 (right)
GND
MIC 0 (left)
PTT 0 (left)
HEAD 0 (left)
GND
LSP (+)
LSP (-) (do not connect to GND)
20 cm
EXT NF
50 cm
INTERCOM SWITCH
green
GND
blue
80 cm
GND
REMOTE RX
brown
REMOTE TX
white
+5V to REMOTE
green
blue
200 cm
BATT (+) (14/28VDC)
BATT (-)
Dok.-Nr. 01.142.010.71d / Revision 1.00
AMP Connector Male
AMP Connector Male
yellow
white
blue
orange
white
blue
violet
brown
External NF
with shorting plug
Powered aircraft:
Intercom Activation
2
3
8
5
red
black
Speaker
Gliders: 4 – 8 Ohm
Motor Gliders:
Use On/Off Switch
REMOTE
RS232 / +5V REMOTE
D-SUB DE-9 Female
(seen from contact side)
Circuit Breaker or Fuse
4A slow
+
-
