Remove the four rubber pads on the button of the projector, you will see the
2.
screw holes and use the M4*10mm screws for installing the ceiling, and then install it.
START USING: POWER ON
Plug the power cord into
an outlet.
PROJECTOR DISTANCE & SIZE
The recommended projection screen is around 80 inches with a projection distance of
around 2,77 m. Ambient darkness will improve the clarity of the projected images.
Screen Projector
Diagonal Distance
41,6" (106
cm) 144 cm (56,7")
50" (127 cm) 173 cm (68,1")
80" (203 cm) 277 cm (109,1")
100" (254 cm) 346 cm (136,2")
120" (305 cm) 416 cm (163,8")
150" (381 cm) 520 cm (204,7")
200" (508 cm) 693 cm (272,8")
Take off the lens
cover.
4:3 width 4:3 height
85 cm (33,5") 64 cm (25,2")
102 cm (40,2") 76 cm (29,9")
162 cm (63,8") 122 cm (48")
203 cm (79,9") 152 cm (59,8")
244 cm (96,1") 183 cm (72")
305 cm (120,1") 229 cm (90,2")
406 cm (159,8") 305 cm (120,1")
Press the
power button
to turn on the
projector
16:9 width 16:9 height
68 cm (26,8") 38 cm (15")
81 cm (31,9") 46 cm (18,1")
130 cm
(51,2") 73 cm (28,7")
163 cm
(64,2") 91 cm (35,8")
195 cm 110 cm
(76,8") (43,3")
244 cm 137 cm
(96,1") (53,9")
325 cm (128") 183 cm (72")
