tool is used; In order to protect the operator, user should wear
gloves and ear protectors in the actual conditions of use.
PACKING LIST
PART NAME
Cultivator Attachment
Guard (with bolt)
Allen Key
Operator's Manual
DESCRIPTION
KNOW YOUR EDGER ATTACHMENT (Fig.A)
1. End Cup
2. Cultivator Attachment Shaft
3. Gear Box
4. Sleeve
5. Outer Blades
6. Inner Blades
7. Hitch Pin
8. Guard
9. Allen Key
ASSEMBLY
WARNING: If any parts are damaged or missing,
do not operate this product until the parts are
replaced. Use of this product with damaged or missing
parts could result in serious personal injury.
WARNING: Do not attempt to modify this product
or create accessories not recommended for use with
this product. Any such alteration or modification is
misuse and could result in a hazardous condition
leading to possibly serious personal injury.
WARNING: To prevent accidental starting that
could cause serious personal injury, always remove
the battery pack from the machine when assembling
parts.
MOUNTING THE GUARD
WARNING: Always wear gloves when mounting or
replacing the guard. Take care of the blade on the
guard and protect your hand from cutting.
WARNING: Never operate the machine without
the guard firmly in place. The guard must always be
on the machine to protect the user! When the guard is
fixed, never attempt to remove or adjust the guard, if
a replacement is needed, it should be performed by a
qualified service technician!
1. Loosen and remove the bolt from the guard with the
Allen key (Fig. B).
QUANTITY
2. Lift the cultivator attachment shaft and remove the
end cap from the shaft.
1
3. Aligned the slot in the guard with metal tab on the
1
end of the shaft, pass the guard through the shaft
1
until the screw holes in the guard and in the metal
tab are aligned (Fig. C & D).
1
4. Use Allen key to tighten the bolt clockwise to lock the
guard securely.
Fig. D parts description see below:
D-1
Bolt
CONNECTING THE CULTIVATOR ATTACHMENT TO
THE POWER HEAD
WARNING: Never attach or adjust any
attachment while the power head is running or with
the battery installed. Failure to stop the motor and
remove the battery may cause serious personal injury.
This cultivator attachment is designed for use with EGO
Power Head PH1400E/PH1420E/PHX1600.
1.
Stop the motor and remove the battery pack
2.
Loosen the wing nut on the power head coupler.
3. If the end cap is on the attachment shaft, remove it
and save it in a safe place for later use.
Align the arrow on the cultivator shaft with the arrow on
the coupler (Fig. E) and push the cultivator shaft into the
coupler until you hear a clear "CLICK" sound(Fig. F).
Fig. E parts description see below:
E-1
E-2
E-3
E-4
E-5
Fig. F parts description see below:
F-1
Red Line
4. Slightly pull the shaft of the cultivator attachment
to verify that it is securely locked into the coupler. If
not, move the cultivator shaft back and forth in the
coupler until a clear "CLICK" sound indicates that it is
engaged.
CULTIVATOR ATTACHMENT — CTA9500
Shaft-Release Button
Arrow on the Coupler
Wing Nut
Arrow on the Attachment Shaft
Red Line
EN
