3.4.8 Clearance around the table
25 mm
Allow a minimum clearance of 25 mm from the edge of a cabletop
moving parts.
When changing the tabletop position (especially without using pinch protection),
there is a risk of pinching. You must therefore ensure that no people or objects are
located in the hazardous area or can reach into it.
3.4.8 Screw points on cabletop
To attach accessories under the table top, use only the green marked area. Don't
screw any screw on the top Surface of the table top.
Only use screws that are screwed into the material with a maximum length of 10 mm.
Cable position
Free mounting surface
(Accessories)
25 mm
®
25 mm
to a wall or
®
ACTIFORCE MECHATRONICS TECHNOLOGY SDN. BHD.
ONCE PRINTED CONSIDER REFERENCE ONLY
(Not subject for revision change)
EN
15
