4
Assembly
4.1
Assembly instructions
The GSM unit is assembled as shown in fig. 2.
5
Installation and operation
5.1

Operating and display elements

The operating and display elements are shown in fig. 3.
Key to fig. 3
1
Multi-LED for status display
2
Connection of the CMC III Processing Unit RJ 12/RS 232, 24 V
item 7)
3
SIM card chassis
4
Button for ejecting the SIM card
5
Aerial connection
6
Aerial
7
Connection of the CMC III Processing Unit RJ 12/RS 232, 24 V
item 2)
5.2
Settings
A number of SIM card settings must be made via the CMC III PU website before connecting the
GSM unit.
In the browser, enter the IP address of the CMC III PU in the network. The login dialog for logging
in to the device will be displayed.
Log in with the username admin and the password admin.
In the left-hand section of the overview window (navigation section), click on the Processing
Unit entry and in the right-hand section (configuration section), click on the Configuration tab.
In the group box Network, click on the SMS button.
In the SMS Configuration window, in the group box Service Parameters, enter the four-digit pin
number of the SIM card in the GSM SIM-Pin field.
In the same group box, enter the provider's text service number (depending on the selected SIM
card/provider) in the GSM Service Number field. For example, Deutsche Telekom D1:
+491710760000.
Click on the Save button to change your settings.
5.3
Installation
Press the button to eject the SIM card (fig. 3, item 4). The SIM card holder will be ejected from
the chassis (fig. 3, item 3).
Insert your SIM card into the holder and push the holder and SIM card fully into the chassis.
Screw the aerial into the relevant connection at the rear of the GSM unit (fig. 3, item 5).
Be sure to erect the aerial where there is an adequate signal at all times from the SIM card's net-
work operator. A longer connection cable for the aerial might be needed in order to achieve this.
Connect the GSM unit to the CMC III PU using an RJ 12 connection cable (fig. 3, item 2 or
item 7).
Rittal CMC III GSM unit
Assembly, Installation and operation
, 500 mA (alternative to
, 500 mA (alternative to
EN
7
