FS UMC-GA1F1T Schnellstartanleitung Seite 7

LEDs
TP/LNK
1000M
FX/LNK
PWR
UMC-GA1F2T
6 EN
State Description
Link through the copper port is
Green
successfully established, but no data
transmission.
The copper port is actively sending or
Blinking
receiving data.
Green
O The copper port is linked down.
The copper port is operating at
Green
1000Mbps.
The copper port is operating at
O
10/100Mbps.
Link through the ber port is
Green successfully established, but no data
transmission.
Blinking The ber port is actively sending or
Green receiving data.
O The ber port is linked down.
Green The device is powered on.
TP1/LNK TP2/LNK FX/LNK PWR
