1. Insert an SFP transceiver into the SFP port.
2. Connect a ber optic cable to the transceiver. Plug the other
end of the ber optic cable into the ber network.
NOTE:
supported. Make sure both sides of the transceiver are
with the same media type.
Connecting the SC Port
Connect one end of a ber optic cable to the SC port and the
other end to the ber network. TX and RX must be paired at both
ends.
NOTE:
by default. Please verify whether the SC cable matches
the converter (single mode or multimode).
Both multimode and single mode cablings are
The media converter is installed with the SC port
