1x
Legen Sie die Acrylplatte auf
den Innenrahmen.
Place the acrylic plate on the inner frame.
Umieść płytę akrylową na wewnętrznej ramie.
2 x
2 x
Z-Profile lang
Z-Profile long | Długi profil Z
Legen Sie die Z-Profile oben
auf das Acrylglas.
Place the Z-profiles on top of the acrylic glass.
Umieść profile Z na płycie akrylowej.
Z-Profile kurz
Z-Profile short | Krótki profil Z
9
