900 — — 1.5
1000 — — 1.5
1250 — — —
1500 — — —
1750 — — —
2000 — — —
The mentioned max. pulse lengths are calculated
with the condition that pause is ≥ pulse length.
9 Standard Operation
During standard operation, the CPA 01 outputs puls-
es according to the volume that has flowed through
and the set pulse valency. The pulse is output with a
latency of 1 second.
If the pulse frequency exceeds 1/sec, the pulses of
the last second are evenly distributed over the cur-
rent second.
10 Test Mode
In test mode the CPA 01 can provide 0.1 and 0.01 li-
tre pulses. The max. pulse frequency is 300 pulses
per second. This equals a flow rate of 100 m³/h with
0,1 litre/pulse and 10 m³/h with 0,01 litre/pulse. The
0.01 and 0.1 litre pulses can be switched on with the
Diavaso Config app exclusively. In test mode the
pulse mode is always A3.
11 Maintenance
The CPA 01 works maintenance free.
10 100 500
10 100 500
10 100 500
10 100 500
10 100 500
5 50 500
12 Transportation
• The CPA 01 should be shipped dry and prefera-
bly frost free.
• The CPA 01 should be shipped always in the pro-
vided box to avoid damage.
• Temperature range during transportation (-10)
0 ... +70 °C
13 Storage
• The CPA 01 shall be stored dry, cool and dust
free.
• The CPA 01 should be stored always in the pro-
vided box to avoid damage.
• Storage temperature (-10) 0 ... +70 °C
14 Disposal
The CPA 01 contains a lithium battery. In the interest
of protecting the environment, this device may not
be disposed in household waste after its period of
use. The local and national regulations for environ-
mental protection are to be considered.
*) in test mode
