2.
Field of application
A mobile dryer is an essential aid for paint repair on
small and medium-sized areas. It is used to acceler-
ate the drying of putty, filler, base and top coats.
This applies to both water-based and solvent-
based products. Its site of use is the preparation
area and finishing area. Within the automotive in-
dustry and vehicle repair sectors, it is used to dry
small areas and cure materials on vertical surface
before polishing.
3.
Product description
The easily manoeuvrable IRT 3 PrepCure is
equipped with a compact cassette. The cassette is
equipped with 3 IR lamps with gold coated reflec-
tors and a ventilator. The design makes cassette
adjustments simple. The IR lamps and reflectors
are protected against mechanical damage with
a mesh. The control unit enables flash off (50%
power) and full bake (100% power). The time can
be set individually for each mode (0-30 min).
3.1 Particular advantages
3.1.1 Higher quality
Using the mobile dryer when you dry putty also
improves the quality of the top coat. The high
surface temperature and curing from the inside
outwards drive all solvents and other reaction
products from the coated material.
3.1.2 Short drying times
Putty
Filler
Primer
Water-base
Base coat
Top coat
Clear coat
3.1.3 High tech shape of reflectors
By using short-wave technology and gold coated
reflectors with a high tech shape we achieve im-
portant advantages.
•
First, by radiating only the needed areas and not heat-
ing any air, a lower energy consumption is achieved.
•
Secondly, a more even surface temperature is
obtained by distributing the energy evenly.
•
Thirdly, a larger drying surface is achieved.
•
Fourthly, less radiation outside the curing area.
3.1.4 Good maneuverability
The units low weight makes the dryer very com-
petitive, versatile and easy to use.
3.2 Technical data
Electrical diagram, see chapter 11.
For dryer reach and dimensions, see last page.
4
2 - 4 min.
4 - 8 min.
6 - 9 min.
2 - 4 min.
5 - 9 min.
7 - 12 min.
6 - 12 min.
Rated Voltage
220V - 240 V, 50/60Hz
Single Phase
Rated power
3 emitters, full power 3000 W
Heating elements
3 quartz, tungsten filament,
InfraRed emitters
Fuse*
16 A slow, type C (UK 13A) (NA
20A)
Drying surfaces on
1,0 m x 1,1 m (width x height)
black sheet metal
Dimensions
See last page
Weight
23 kg
Noice level
Less than 70 dB (A)
Max ambient tempera-
ture during operation 40
o
Max ambient tempera-
ture during storage
and transportation
70
o
* The dryer must be supplied by recommended fuse.
4.
Instruction to the owner
The owner of the mobile dryer must produce clear op-
erating instructions, adapted to local site conditions,
and make these available to all users. Mobile dryer
users must adhere to these operating instructions.
This appliance is not intended for use by persons
(including children) with reduced physical, sen-
sory or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Dispose of spent items at the nearest environmen-
tal protection facility for recycling.
5.
Hazards
Fire and explosion
To reduce the risk of explosion, do not use in paint
spray booths or within 5 m/16 feet of paint spraying
operations. Do not store, prepare or use solvent-
containing materials within a 5 m/16 feet radius of
the mobile dryer. Flammable materials should not
be placed close to a drying device in use.
If you have a distance less than 60 cm/2 feet to
the object the temperature might raise quickly
and the risk for fire increases. Never direct the
cassette towards highly combustible materials.
Electrical equipment
The mobile dryer is operated by highly dangerous
electrical voltage.
Accessing electrical equipment
CAUTION! Disconnect all power supplies before
opening panel.
Before accessing live parts, remove the main con-
nector from the wall socket. Only professional
electricians may have direct access into the electrical
equipment. If the supply cord is damaged, it must
be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
WARNING!
Intensive heat radiation. Hands, face and other
parts of the body should be exposed as little as
possible to the heat radiation.
IRT 3 PrepCure
Celsius
Celsius
714377 rev 4
