Electrical characteristics
VSWR
Mechanical properties
Connector
Dimensions
(width x height x depth)
Weight
Material of the antenna housing
Material of the rear plate
Degree of protection
Wind load front
Wind load from the side
Storage and operating temperature
6 Dimension drawings
Dimensions are specified in mm.
Antenna
Rear view and side views
Antenna ANT793-8DJ
A5E03484059-07, 08/2023
1.7
2 x N-Connect female
190 x 190 x 30 mm
700 g
Polycarbonate
Aluminum
IP67
104 N at 220 km/h
16 N at 220 km/h
-45 °C to 70 °C
