182
RS-9
Specifications
Inputs
MIDI In
Type
5 pin DIN
USB In/Out
Type
USB-C
Reset In
Type
3.5 mm TS jack, DC coupled
Max input level
10 V
Sync In
Type
3.5 mm TRS jack, DC coupled
Max input level
10 V
Outputs
Trigger Out
Type
10 x 3.5 mm TS jack, DC coupled
Impedance
1 kΩ, unbalanced
Max output level
10 V p-p
Accent Out
Type
10 x 3.5 mm TS jack, DC coupled
Impedance
330 Ω, unbalanced
Max output level
10 V p-p
Sync Out
Type
3.5 mm TRS jack, DC coupled
Impedance
220 Ω, unbalanced
Max output level
5 V p-p
MIDI Out
Type
5 pin DIN
Controls
Knobs
Accent Level, Multi-function
Track Select x 10
Accent
Tap, Record, Stop, Play/Pause
Autoscroll, <<, Length, >>
Song, Pattern, Step
Save, Copy, Erase, Dump
Mode, Sync
Buttons
Trigger, Step Repeat, Note Repeat,
1, 2, 4, 8
Track Mute, Track Solo
Autofill, Settings
MIDI, USB, Clock, Map, Prefs, CV, Poly,
Rand, Prob
Flam, Repeat, 1/8, 1/8T, 1/16, 1/16T, 1/32
4 character 7 segment LED
Power
Power supply
Eurorack
Current draw
+12 V 350 mA / -12 V 20 mA
Physical
Standard operating
5° C to 45° C (41° F to 113° F)
temperature range
263.8 x 128.5 x 41.1 mm
Dimensions
(10.39 x 5.06 x 1.62 ")
Rack units
52 hp
Weight
0.51 kg (1.12 lb)
183
Quick Start Guide
