English
Introduction
Your monitor has been designed and
manufactured to the highest standards.
and subjedt to rigorous testing. Prov'idedit
is properly operated and maintained it Will
perform well tor manyyears.
This colour monitor is suitable for use with
home and personal computers, video
recorders, LaserVision Players and TV
Tuners.
n Connectio to themains(For
Your new monitor is designed to operate
from an a.c. mains supply of 220-240 volts,
50 HZ Stabilising circuits ensure
satisfactory performance within normal
supply variations.
Important: This apparatus must be
earthed. This can be achieved by fitting a
3 pin plug The wires in the earthed
mains lead are coloured accor&ng to
the following code:
= NEUTRAL
BLUE
BROWN = LIVE
GREEN/YELLOW= EARTH
If the mains plug (or adaptor) contains a
fuse. the value of this fuse should be
3 Amp. Alternatively, if another type of
plug (not fused) is used. the fuse at the
distribution board should not be greater
than 5 Amp.
If the Colours Of the wires in the mains
lead do not correspond with the
coloured markings identifying the
terminals in your plug, proceed as
follows
The BLUE wire should be connected
the terrNnal marked •N' Or coloured
black.
The BROWN wire should be connected
to the terminal marked 'L' Or coloured
The GREEN and YELLOW must be
connected to the terminal in the plug
marked by 'E' or the earth symbol 4, or
coloured green or green and yellow.
Before replacing the plug cover, make
certain that the cord grip is clamped
over the sheathof the lead - not simply
over the three wires.
positioning/Ventilation
In order to prevent overheating. ensure
that the ventilation openings
are not covered.
The monitor should not be placed near a
source of heat nor on a sott surface since
this would block the ventilation
the bottom
Movable support
only)
You can tilt the monitor into a convenient
position With regard to the computer by
using the movable support.
Connection to the mains
You can connect your monitor to a mains
voltage of between 220 and 240 V, If the
mains voltage in your home is different
from this, consult your dealer.
Connections (rear panel)
for input of video and audio signa's. Each
connector is marked Wi!h its function.
0QQAO
to
CVBS/L (Luminance) IN (Phono type)
CVBS (composite signal) or Luminance
input Phono plug type.
For connection of a computer or other
CVBS sources.
CHROMA IN (phono type)
Chroma (colour signal) of the phono
plug type. For connection of a
computer.
AUDIO IN (Phono type)
For connection of a signa' source with a
sound (audio) signal output.
LCA'CVBS switch
With the LCA'CVBS switch
either choose the LCA signal or the CVBS
signal (via euroconnector or phono plug).
the monitor
TTL R GB i nput (8pin DIN type 2701TL
For connection of a computer with a
RGB output with
synchronisation
slots on
Connection (left panel)
Headphones
On the left side Ofthe monitor you will find
a 3,5 mm •ack-type sæket for connecting
the headpkones
Operation
Switching on
• Press button O (LED lights up).
Switching Off
• press button O again,
Picture and sound
For an optimum adjustment Of the Video and audio input signa's various Controls are
available.
• Open flap @
you can
CVBS + RGB linear + Audio input
rated
(Rlavel).
(Euroconnector type)
For connection Ofa Video Recorder.
Computer, LaserVision Player, TV Tuner,
etc. equipped
Remark:
It you connect both RGB inputs
simultaneously the TTL RGB input
automatically has priority over the linear
RGB input.
After switching off or removing the
connection
RGB linear will be looped in.
Furthermore you can connect a CVBS
source
Tuner,etc.) to one ot the CV3Sinput
sockets. but not on both input sockets
simultaneousty because this might result in
controls
With a Euroconnector.
cable from the TTL Source.
(computer, Video Recorder.
dsturbance.
POWER
