Keep the instructions for future.
NF-EN-14619: 2019
READ THE INSTRUCTIONS PROVIDED BY THE MANUFACTURER BEFORE
USING. MAXIMUM WEIGHT: 50 KG
Warnings
- The scooter is suitable for adolescents and adults. It is not a toy, but sports
equipment for physical training, it is not intended for use in extreme sports such as
jumping, ollie ramps, etc. This product should never be used at a skate park for an
"aggressive" use (challenging skateboarding moves, etc.).
- U se with caution on a flat, clean, dry surface and, if possible, away from other
users, and obey the road safety rules.
- C heck local laws regarding scooter use, respect all the traffic rules and signs.
Stay away from other pedestrians or users on public roads.
- B est when used on a flat, dry surface free of gravel and grease. Avoid bumps and
drainage grates that might cause an accident.
- Warning! Protective equipment consisting of wrist protectors, gloves, knee pads,
helmets and elbow pads should be worn.
Using the scooter
• Before and after each use: To prevent pinched fingers, carefully follow the
instructions of unfolding and folding. Make sure that the locking mechanisms are
securely locked:
- Check the height of the steering system and make sure that the nuts are
tightened and the handlebars and front wheel are perpendicular.
- Check all of the connection elements: the brake, the quick release system of the
steering column and the wheel axles must be correctly adjusted and must not
be damaged.
- Also check the tire wear.
• Braking:
- A brake is located at the rear, when necessary, press down on it to slow down.
Press down gradually to prevent skidding or loss of stability. The metal brake may
heat up after multiple uses. Avoid touching it during and after use.
- If model with the handlebar brake: a right brake handle to slow the back wheel.
When using, keep riding the scooter with both hands.
Assembling the product
- The folding and unfolding operations of the scooter are to be done by a single
person.
- D uring these operations, be careful you do not get your fingers stuck in the hinge
and locking system.
- Make sure that the locking devices are properly engaged.
6
1 - Unfold the scooter
D1: Unpack the folded-up scooter from its box.
D2: Push in the button. At the same time, pull the metal part, which will cause the
handlebars to open. Then straighten the steering column until the button locks
into position.
(If it is difficult to fold or unfold scooter while operating, please use M4 allen tool
to loose hex screw one turn as the photo showed. Don't loose the hex screw too
much; the hex screw will be lost.)
D3: Open the clamp lever on the T-bar. Remove the plastic insert. Pull out both
parts of the T-bar handle from the double clips. Press in the spring loaded buttons
and insert both into the tubes of the T-bar. Wiggle and turn a bit until their spring
loaded locking buttons align with the holes and fix the whole steering bar assembly
in place. Close clamp lever.
Warning! Risk of injury by pinching!
Do not insert your fingers into the shaded area indicated
2 - Adjust the handle bar
D4: Open the fixing lug. Then press down the spring loaded locking button and pull
the handlebar up or push it down with the other hand.
Choose the suitable locking hole and make sure the spring loaded locking pin
snaps securely in place. The adjustable T-bar handle can be adapted in height to
suit the rider.
4 different positions are available.
Lock the fixing lug tight and securely when you have finished adjusting the height.
3 - Fold up the scooter
D5: Lift up the kick stand. Push in the button while pulling on the metal part, which
will cause the steering column to close. Release the button when the steering
column begins to fold up. The button will position itself in its locking position when
the steering column is completely folded.
D6: For purposes of storage, remove both parts of the T-bar handle from the T-bar.
Open the clamp lever on the T-bar. Press down the spring-loaded locking pins
while pulling out the part sideways at the same time. Strings inside the tubes will
hold the individual part together. Clip the two parts of the T-bar handle into the clips
to both sides of the steering bar (refer to D3 in reverse order). Close clamp lever.
During use:
- Lift up the kick stand.
- Standing on the scooter, with one hand on each handle, push with one of your
feet to move forward. Proceed with caution at the start.
- Always wear shoes and we strongly recommend wearing pants and long sleeve
shirts to avoid injury if you fall.
- The scooter does not include any headlights or lights. It is therefore not suitable
for use at night or during periods when visibility is limited.
DO NOT FORGET TO REGULARLY TIGHTEN ALL BOLTS AND SCREWS TO
AVOID MISALIGNMENT OR LOSS OF THE SCREW.
Care / Maintenance: regular maintenance is a safety commitment;
- Wheel bearings: avoid going through water, oil or sand as this can damage
wheel bearings. To look after the wheel bearings, systematically check that the
wheels turn properly by turning the scooter upside-down and using your hand
to spin the wheels. If the wheels do not spin they must be removed to check
their condition. First unscrew the wheel axle, remove the axle and detach the
wheel, then carefully push the two wheel bearings out of their housing. If they are
chipped or dented, new ones should be bought. If there is no visible damage,
they must then be oiled. To do this, remove all traces of grease, mud or dust with
a kitchen towel or cloth, and re-oil them with a grease spray or by leaving them to
soak overnight in oil [turn them several times in the oil first]. Then reassemble the
wheel bearings and axles, followed by the wheel, onto the scooter. Proceed in the
same manner for the other wheel.
- Wheels: the wheels wear down with time and can be pierced if overly used on
rough surfaces. The back wheel on which the brake is applied is particularly
affected after several hours of braking. In the interests of safety, they should be
checked regularly and changed if necessary.
- Modifications: the original product must by no means be modified except for the
maintenance-related changes mentioned in these instructions.
- Nuts, axles and other self-locking fixings: these should also be checked
regularly. They can become loose after a while in which case they should be
tightened. They can become worn and not tighten properly, in which case they
should be replaced.
Additional Info
For questions and inquiries please contact us at: contact@globber.com
WARRANTY
The manufacturer warranties this product to be free of manufacturing defects for
period of 2 years from date of purchase. This limited Warranty does not cover
normal wear and tear, tire, tube or cables, or any damage, failure or loss caused by
improper assembly, maintenance, or storage.
This Limited Warranty will be void if the product is ever
• used in a manner other than for recreation or transportation;
• modified in any way;
• rented
The manufacturer is not liable for incidental or consequential loss or damage due
directly or indirectly to the use of this product.
Globber does not offer an extended warranty. If you have purchased an extended
warranty, it must be honoured by the store at which it was purchased.
For your records, save your original sales receipt with this manual and write the
product name below.
...................................................................................
Spare parts
To order spare parts for this product, please visit our website: globber.com
