5
Technical data
5.1
Torques
Description / use
PT-screw 100x30 A2
Fastening clamp / on tank
Pipe clamp D=120
Pipe clamp D=84
5.2
Pre-conditions / basis for calculation
The parameters for operation (disposal) of the grease separator are based on these values:
–
Pumping capacity (extraction capacity) of the disposal vehicle 10 l/s = 36 m³/h.
–
Cold / hot water supply 1l/s with DN25,
–
Room temperature at least +15° C.
010-296
Torque Nm
7
3
8-10
8-10
26 / 88
Spanner size
T50
ISK 10mm
Socket 13mm
Socket 13mm
2019/08
