1.3
General information on these operating and maintenance instructions
Symbols and keys used
<1>
[2]
•
3.
–
Italics
1.4
Assemblies and functional characteristics
The figure shows the system types Standard and Direct
Standard
1
1 Inlet
2 Refill inlet (optional)
3 Type plate
4 Outlet
5 Direct disposal pipe
6 Inspection window (optional)
2019/08
Reference in the text to a key number in a figure
Reference to a figure
Work step
Work step in numbered order
List
Italic type: Reference to a section / item in the control menu
CAUTION: Warns of a hazard for persons and material. Disregard of the instructions marked with this
symbol can lead to serious injuries and material damage.
Note: Technical information or instructions to which particular attention must be paid.
2
4
Fig. [1]
3
6
19 /88
Direct
1
5
4
010-296
