Sharp FN4EA Bedienungsanleitung Seite 10

8
3. Select [Scan] and press OK.
4.
Select the satellite you want to tune and confi rm by pressing the OK
button.
5.
Select [Next] and press OK.
6.
After a few seconds, the Operator List will appear on the screen. Select
your operator/service and confi rm with the OK button.
7. In a short while, all the channels of your operator are tuned and sorted
and you can start watching TV.
Connecting to a network
Connecting to a network using a LAN cable
A wired LAN connection allows you to access the Internet and your home
network. Make sure to connect to the Internet or home network via a
router.
1.
Set up your LAN router. For details, refer to the instruction manual of
your LAN router.
2.
Connect LAN cable from router to the TV.
After connecting LAN cable, TV should connect to the internet
automatically if DHCP is activated on your router.
In case you set up on the router static IP address for the TV, you will need
to follow these steps:
1. Press the HOME button, then select [Settings] — [Network & Internet]
— [IP settings] — [Static]
2. Now follow the on-screen instructions and fi ll in correct IP Address,
Gateway, Network prefi x length and DNS.
Connecting to a network using a wireless connection
The built-in wireless LAN device allows you to access the Internet and
enjoy the benefi ts of networking in a cable-free environment.
1. Set up your wireless router. For details, refer to the instruction manual
of your wireless router.
2. Press the HOME button, then select [Settings] — [Network & Internet].
3. From the list of available networks choose your wireless network.
If you do not see your Wi-Fi network, select [See all] option to show
the complete list of all available networks.
4. On the virtual keyboard enter password of your network
To turn off the built-in wireless LAN
To disable built-in WiFi, press the HOME button, then select [Settings] —
[Network & Internet] — [Wi-Fi].
Live TV menu
Source
To get to the Live TV menu, press the SOURCE button and select one of
available inputs. Then press the MENU button.
Source menu allows you to switch between inputs/connections.
NOTE
Available connections depends on the TV model.
Picture Mode
To get to the Live TV menu, press the SOURCE button and select one of
available inputs. Then press the MENU button.
This menu provides options to modify picture quality.
Available options
[User]
Allows you to change the picture settings to your personal preference.
These settings are saved automatically.
[Standard]
Standard settings.
[Vivid]
Enhances picture saturation and sharpness.
[Sport]
Optimises picture quality for viewing sports.
[Movie]
Picture has less colour and is darker.
[Game]
Recommended settings for gaming. The TV will turn off all picture post
processing functions to achieve minimal input delay.
[Energy Saving]
Power saving mode, which reduces the energy used by up to 20% (by
reducing the power to the LED/LCD panel). In this mode, the brightness of
the picture may be reduced.
NOTE
Depending on TV model, some picture mode options may not be available.
Display Mode
To get to the Live TV menu, press the SOURCE button and select one of
available inputs. Then press the MENU button.
This menu provides options to change picture aspect ratio of current
source.
Available options
[Automatic]
Automatically displays the best picture format so the picture is in the
correct position. Black lines may appear at the top/bottom and/or sides.
[Super Zoom]
Displays a 4:3 picture at a 16:9 size; the picture is stretched horizontally and
vertically and its left and right edges are enlarged. This crops out some of
the top and bottom of the picture.
[4:3]
Displays a 16:9 picture at a 4:3 size; the picture is shortened horizontally.
Sidebars appear on both edges of the screen.
Displays the 4:3 picture in its original size. Side bars are shown to fill the
16:9 screen.
[Movie Expand 14:9]
Displays a 4:3 picture at a 14:9 size; the picture is stretched horizontally
and vertically. This crops out some of the top and bottom of the picture.
Sidebars appear on both edges of the screen.
[Movie Expand 16:9]
Displays a 4:3 picture at a 16:9 size; the picture is stretched horizontally and
vertically. This crops out some of the top and bottom of the picture.
[Wide Screen]
Displays a 16:9 picture that is stretched horizontally and vertically.
Displays a 4:3 picture that is stretched out of proportion to fi ll the screen.
[Full]
Displays a picture in the full screen mode. 16:9 signal will be displayed
in original proportion. Other picture formats will be stretched to fill the
screen.
[Unscaled]
Displays a picture in its original resolution in the middle of screen. If the
picture has lower resolution than the TV, there will be black bars on all four
sides of the picture.
Power
To get to the Live TV menu, press the SOURCE button and select one of
available inputs. Then press the MENU button.
Changes the settings related to power consumption.
Available options
[Sleep Timer]
Lets you set the sleep timer so the television automatically switches off
after a set amount of time.
[Picture off ]
Allows you to turn off display. To turn display back on, press the STANDBY
button on the remote control.
[Switch Off Timer]
Controls the amount of time the set will continue to operate without any
buttons being pressed on the set or remote control before going into
standby.
[No Signal Auto Power Off ]
Controls the amount of time the set will continue to operate without any
buttons being pressed while switched on input, which does not receive
signal.
[Auto Sleep]
Controls the amount of time the set will continue to operate without any
