Positive break travel
Positive break force per NC contact, minimum
Positive break force, minimum
Actuating speed, maximum
Mounting
Type of the fixing screws
Type of the screw head
Tightening torque of the fastening screws for the housing cover
Note
Mechanical data - Connection technique
Cable entry
Termination
Cable section, minimum
Cable section, maximum
Note
Allowed type of cable
Mechanical data - Dimensions
Length of sensor
Width of sensor
Height of sensor
Ambient conditions
Degree of protection
Ambient temperature
Storage and transport temperature
Note (Relative humidity)
Protection class
Permissible installation altitude above sea level, maximum
Ambient conditions - Insulation values
10 mm
10 N
20 N
2 m/s
Screws
3x M5
Flat head screw
0.6 Nm
The tightening sequence of the cover screws must be observed. This
can be found in the attached drawing in the "Pictures" tab.
4 x M16 x 1,5
Cage clamps
0.25 mm²
1.5 mm²
All indications including the conductor ferrules.
solid single-wire
solid multi-wire
flexible
30 mm
130 mm
90 mm
IP67
-30 ... +60 °C
-30 ... +85 °C
non-condensing
non-icing
II
2,000 m
6-19
