Forpanel
Kontrolknap for krydsfaderkurve
(C.FADER CURVE) .........................................................
Kurveknap (CURVE)
Krydsfaderbetjeningsknap (CROSS FADER)
Faderbetjeningsknap (CH1 – CH4 FADER)..................
Hovedtelefonterminal (PHONES) .................................
Faderstart (ON, OFF) knap (FADER START)................
Bagpanel
Tænd/sluk-knap (POWER
Jordtilslutning til pladespiller (PHONO EARTH).........
Indgangsterminal (CH1 – CH4) .....................................
CD/LINE: CD- eller linieterminal
LINE: Linieterminal
PHONO 1 – 3: Phonoterminal til pladespiller
Mikrofonindgangsterminal (MIC1, MIC2) .....................
Effektor-indgangs/udgangsterminal
(EFFECT RETURN, EFFECT SEND) .............................
Afspillerkontrolterminal (CH1, CH4)
(PLAYER CONTROL) .....................................................
Digital udgangsterminal (DIGITAL OUT)......................
Digital indgangsterminal (CH1, CH4)
(DIGITAL IN)....................................................................
Udgangsterminal ...........................................................
Hovedudgangs 1, 2 terminal (MASTER OUT)
Monitor-udgangsterminal (MONITOR OUT)
Optageterminal (REC OUT)
Strømindgangsterminal (AC IN ~) ................................
OFF ON)...................
